HUST CNC H6D-B3 MANUAL
33
Appendix 5：H4CL-B Control Structure of Bending Machine
Fig 43
Control Box
X
Driver
Y
Driver
Slip and Stop
for Y-axis
SEVRO
X-axis stop material ledge
SEVRO
Oil - System
R
Driver
R-axis stop material ledge
SEVRO
Bending switch
Oil-Stop（output）
