Appendix 10：Install Manual
(1) Test the I/O signal.
(2) Adjust the parameter of servo motor and controller.
(3) Check the direction of servo motor:
The Y (D) axis direction must depend on the machine.
Illustration is below：
EX 1. O-TYPE (Open Type)
Y – opening default
= 450
Fig 60
※ The coordinate displayed by controller is the actual position when machine
opening.
Slip and Stop
for Y-axis
X-axis stop
material ledge
＋ －
0
250
450
＋ －
0
350
450
R-axis
＋
－
