HUST CNC H6D-B3 MANUAL
3
2. AUTO mode : (main page)
Fig 4
(1) Function key：
a. CYCST：Cycle start
(a) Press this key to run the program.
(b) When the program is running, the LED-light located left-up of the
CYCST will be on. Then the number of piece bended will begin to be
counted.
b. RESET：
CNC gives an order to controller that let it stay on the non-mode, and the
frame jumps to the non-mode page.
c. Edit :
When pressing this key on any mode, the controller will execute RESET first.
Let the controller stay on non-mode status and then jump to the file-set page.
d. Set：
When pressing this key on any mode, this key will highlight. It means that the
controller is not running any program. And use CURSOR key to set the value
of Total-Cor.(Gα), SD-Pos., Total-number(T-Time) 【Material】、【Depth】、
【Pre.-BL】and Count number(C-Time).
e. FORWARD : Execute last program
Do not press the NEXT key again when the white light is not canceled.
Because the program is not running over.
f. NEXT : Execute next program
Do not press the FORWARD key again when the white light is not canceled.
Because the program is not running over
g. Lock：
AUTO
Next For Edit Set Lock Pre. GRAPH
PRO-RUN
FILE000
Bendin
