HUST CNC H6D-B3 MANUAL
4
When pressing this key, the running program will stop at this step.
※ Press again to cancel.
h. Pre.-BL
Calculate the Bending-Force must be setting the item of 5,6,8.
i. Graph for reference（Graph）
Push this key and enter Graph for reference and establish pages.
(2) Additional description : When the setting key is highlight:
a. Total correction（Gα）:
Programs in the file are all corrected When trying to bending 90 degree, the
angle is not enough : Set value positive too deep : Set negative value
EX 1 :
(a) The Y-axis（D-axis）movement of one unit is set as 0.01 ( P-αD = 0.01 ).
Set in the mode of Edit－FOLD－UN-SET.
(b) Gα= 5.000 ( total correction )
(c) The unit of the total correction is
P-αD × Gα÷ 1000 = 0.010 × 5000 ÷ 1000 = 0.05 mm
EX 2 :
(a) The Y-axis（D-axis）movement of one unit is set as 0.04 ( P-αD = 0.04 ).
Set in the mode of Edit－FOLD－UN-SET.
(b) Gα= 5.000 ( total correction )
(c) The unit of the total correction is
(d) d. P-αD × Gα÷ 1000 = 0.040 × 5000 ÷ 1000 = 0.2 mm
b. SD-position :
Input the location of angle-axis directly. Then press 【CYCST】key to execute
it. When the position is arrived, the number of D-axis will be canceled
automatically. At this time we can press【CYCST】key to run the program
directly.
c. T-Time :
Set total number of pieces
d. C-Time :
When it has run all the programs, the number will be added by 1 (Number of
piece)
e. Material：(Establish the range 0-2)
Establishment：0，Stainless steel 、1，Iron 、2，Aluminium
f. Pre.-BL
g. Calculate the Bending-Force condition needed
h. Thickness：
Input the Bending Machine of project
To Next Page
