Appendix 7：Sanyo Servo Machinery Connection
PY-PZ
【Voltage Command】Connection Diagram
SANYO servo motor setting value ( Voltage Command )
PY SERVO
MODE PAGE ABBREVIATE NAME & ABOUT
STANDARD
VALUE
SETTING
VALUE
1 4 ENCR
Output pulse frequency
division ratio
1/ 1 1/ 3
1 14 VCMS
Analog speed command
maximum output
500 200
2 1 FUNC0 SW0 (Bit 5 = 1) 00000000 00100000
Sanyo PZ
Sanyo PY
HUST CNC
Cable
（3M 以下）
3M
50 PIN
F(D-connector)
9 PIN
M(D-connector)
PIN
Number
Blue 3 1 Blue A
Green 4 2 Green
A－
Brown 5 3 Brown B
Purple 6 4 Purple
B－
White 7 5 White C
Yellow 8 6 Yellow
C－
Orange 21
（Red）
7 Orange VCMD
Light
Blue
20 8 Light Blue
GND
Grey 12 8 Grey GND
White 23
+5V，+24V input
Black 37 SERVO ON
PY & PZ Driver
Controller
