2.4
SHUTTLE CONTROLS
SHUTTLE FORWARD Pressing this key will move the shuttle towards the front of the saw and will stop and hold
its position if the key is released.
SHUTTLE REVERSE Pressing this key will move the shuttle towards the back of the saw and will stop and hold
its position if the key is released.
SHUTTLE SLOW / FAST Pressing this key will toggle between FAST and SLOW shuttle speed. The button display
will indicate FAST or SLOW.
BLADE CONTROLS
BLADE START/STOP Pressing this key will start or stop the blade. The blade will not start if the head is fully
down or if the xed vise is not closed.
RIGHT ARROW KEY
(NAVIGATION KEYS)
Pressing this key will cause the blade speed to increase until the key is released or the
speed is at the maximum (350 SFM). The blade must be running to use this key and the
blade speed is shown on the display screen.
LEFT ARROW KEY
(NAVIGATION KEYS)
Pressing this key will cause the blade speed to decrease until the key is released or the
speed is at the minimum (70 SFM). The blade must be running to use this key and the
blade speed is shown on the display screen.
COOLANT CONTROLS
COOLANT ON Pressing this key will start the coolant ow.
COOLANT OFF Pressing this key will stop the coolant ow.
COOLANT AUTO Pressing this key will cause the coolant to ow only when the blade is running OR when
the blade is running and the head is descending.
MODE CONTROLS
SERVICE MODE The SERVICE MODE allows the user to adjust the various PLC parameters. The user
will be prompted for a password. Contact Hyd-Mech Group Limited to access this mode.
MANUAL MODE Pressing this key will put the saw in MANUAL MODE.
AUTO MODE Pressing this key will put the saw in AUTO MODE. To enter AUTO MODE, the FIXED
VISE must also be activated.
MACHINE & CYCLE CONTROLS
MACHINE START Pressing this key will activate the control panel, display, and start the hydraulic system.
The EMERGENCY STOP button must be pulled out. This key must be activated to use
the machine functions.
MACHINE STOP Pressing this key will shut down all machine functions including the control display and
hydraulic system. The display will not have a back light on. All jobs will remain in memory
as will the QUEUE.
CYCLE START The user will be prompted by the display to press this key as it is used to initiate an AUTO
or SINGLE CUT MODE cycle. Pressing this button will also initiate the QUEUE if pressed
when in the QUEUE screen.
CYCLE PAUSE Pressing this key will pause the cycle in progress. To resume the cycle, press the CYCLE
START key.
