8.1
SECTION 8 - SPECIFICATIONS
H-14A BANDSAW SPECIFICATIONS
Capacity Round 14” (355mm)
Rectangular 14”x 14” (355mm x 355mm)
Length Control Programmable up to 99 jobs
Blade Length 15’-4” (4673mm)
Width 1 1/4” (34mm)
Thickness .042” (1.1mm)
Blade Tension Hydraulic
Blade Speed Variable 50 - 350 so/min (15.5 - 107 m/min)
Blade Guides Carbide inserts (coolant lubricated)
Blade Wheel Dia. 19” (483mm)
Motors Blade drive 7 1/2 HP (5.5 kW)
Hydraulic pump
drive
2 HP (1.5 kW)
Pumps Hydraulic 6 1/2 Gal. / min (25 Liters/min) (pressure compensated)
Coolant 3 1/2 Gal. / min (13.5 Liters/min)
Hydraulic Tank 7.5 U.S. Gallons (28 Liters)
Coolant Tank 15 U.S. Gallons (57 Liters)
System Pressure 700 PHI (4826 kPa)
Vise Control Hydraulic Full Stroke
Shuttle Stroke 0-34” (0-863mm) single stroke, multi-index capability
Table Height 31” (787mm)
Machine Weight 5500 lbs (2495 Kg)
Maximum Workload 6000 lbs (2722 Kg)
Overall Dimensions 97” (2464mm) Wide, 92” (2337mm) Long, 72” (1829mm) High
