3.12
PARAMETER DEFINITION
SPEED CONSTANT
Blade Speed Display adjustment number. If actual blade speed is different than displayed blade
speed, a new SPEED CONSTANT will need to be calculated. SPEED CONSTANT = old SPEED
CONSTANT x actual speed / displayed speed.
HEIGHT CONSTANT
Height calibration factor. Enter manually by overwriting, or correct automatically by Height
Calibration Sequence (previous 2 parameter lines). If actual feed rate differs from displayed
value: Enter new Height Calibration Factor = old Factor x actual feed rate / displayed feed rate.
ACTUAL LENGTH Actual Length Value of shuttle stroke.
LENGTH CONSTANT Species linear distance of shuttle movement in inches per one pulse of shuttle encoder.
ACCELERATION
DISTANCE
Shuttle acceleration distance. Distance, in inches, the shuttle will travel slowly before reaching
fast speed while starting to move in either direction (i.e. 1.000).
DECELERATION
DISTANCE
Shuttle Deceleration distance. Distance, in inches, the shuttle will travel slowly before reaching
home or target position (i.e. 1.000).
MINIMUM FAST
DISTANCE
Minimum fast speed distance. If programmed length is smaller than this parameter, override to
slow speed (shuttle)
TARGET WINDOW Allowable +/- tolerance from programmed length.
FRONT VISE OPEN
DWELL
Delay time for the opening of the FIXED VISE in seconds.
SHUTTLE VISE OPEN
DWELL
Delay time for the opening of the FIXED VISE in seconds.
CLOSE TIME Delay time for the closing of the SHUTTLE or FIXED VISE in seconds.
FEED RATE Activates feed rate display.
ACTUAL POSITION
DISPLAY
If this value is set to YES, displays SHUTTLE VISE actual position
HOLD SHUTTLE HOME Hold SHUTTLE VISE home and closed during cut.
BROKEN PROX
Allows user to override signal from proximity switch in case it is broken. (When set to NO
machine will not run with broken proximity sensor. Set to YES allows machine to run – but with
out blade speed display and blade breakage or stall protection).
MIN BLADE SPEED Minimum blade speed on which blade breakage will be activated.
SPD PROX DELAY
Delay in monitoring of the blade speed proximity switch during acceleration of the blade from
start to desired speed set by the manufacturer
POWER DOWN TIMER
If “0” selected, then the machine will shut down after the job is completed. This will allow the
machine to continue running for a specied time after the job (in Manual Mode) for the cycle (in
Auto Mode) has been completed. Range from “0” to “180” minutes.
BLADE CLEAR
If set to YES, when the AUTO CYCLE reaches the function of head up, the shuttle will retract
the material from the blade by 1/8” before the head will move up. When the head reaches the up
position, the next length of material is shuttled into position.
TRIM CUT
If set to YES is selected, the machine will perform a facing cut of the material at the beginning of
an automatic cycle.
OUT OF STOCK
Selecting YES activates the out of stock option, which prevents the shuttle vise from closing if
insufcient length of material is available for the next length advance. Also stops the automatic
cycle after completing the last cut.
COOLANT
When BLD is selected, coolant ows when the blade is running. When BLD + DWN selected,
coolant ows when the blade is running and head is moving down.
QUEUE
The Queue allows the operator to run several jobs (max 10) in series. If REPEAT is selected the
above series will be executed the selected number of times.
