Hyd-Mech S20DSP User Manual

6--23
67
Code
Description U. of M. Quantity
001.5010 MOTOR WHEEL NR 1,000
010.0355 SELF--LOCKING RING NUT 25X1,5 T NR 1,000
010.0356 SELF--LOCKING RING NUT 45X1,5 S NR 1,000
010.0373 BEARING FIX. RING NUT SH400--42 NR 1,000
010.2139 GEARBOX SHAFT NR 1,000
010.7111 8X7X32KEY NR 1,000
010.7112 8X7X35KEY NR 1,000
010.7604 0 8 WASHER NR 4,000
010.7605 0 10 WASHER NR 4,000
010.7645 M8 SPRING WASHER NR 4,000
010.7891 TCEI 8 X 16 SCREW NR 4,000
010.7893 TCEI 8 X 20 SCREW NR 4,000
010.7895 TCEI 8 X 30 SCREW NR 9,000
010.7963 TE 8 X 25 SCREW NR 4,000
010.7976 TE 10 X 30 SCREW NR 4,000
019.3621 NR 1,000
022.0212 RAPID JOINT SEM PG 16 NR 1,000
025.0121 REDUCER MVF 63 FCO 1A38 90 B14 NR 1,000
025.0625 MOTOR GASKET SH 310 --320--330 NR 1,000
025.0863 CONNECTOR TLK 130 50X80 SH 400 NR 1,000
025.0923 BEARING 3210E--2RS NR 1,000
034.0418 REDUCTOR COVER SH 260 NR 1,000
