ETS 300 15
Stand: 29.01.2014 HYDAC ELECTRONIC GMBH Mat. Nr.: 669651 D
12.2 ANSCHLUSS-SKIZZE
Sensorwiderstand
ETS 38X
Geräteeinbau-Buchse,
4-pol. M12x1
Geräteeinbau-Stecker, 4-
pol. TFP 104
(Binder, Serie 714)
bzw. TFP 106 (M12x1)
