HYDAC ELECTRONIC ETS 300 - Temperature-Probe Tfp 100

20 ETS 300
Status: 29.01.2014 HYDAC ELECTRONIC GMBH Part No.: 669651 E
14.3 TEMPERATURE-PROBE TFP 100
Technical specifications
Temperatur probe TFP 100
Temperature range -40 .. +125 °C (-40 .. +257 °F)
Electrical connection Male Binder series 714 M18, 4 pole
Male M12x1, 4 pole
Parts in contact with fluid Brass
-mark EN 61000-6-1 / 2 / 3 / 4
Sensor current 0,3 .. 1,0 mA
Fitting protective sleeve for tank-mounting the TFP 100
Pressure resistance 10 bar
Parts in contact with fluid CuZn39Pb3 (brass), nickel-plated
Model code
TFP 10X – 000
Separate temperature probe
Electrical connection
4 = Male, 4 pole Binder series 714 M18 (connector supplied)
6 = Male, 4 pole M12x1 (connector not supp)
Modification number
000 = Standard
Dimensions
TFP 104-000 TFP 106-000 Protective sleeve for TFP100
Part No.:904696 Part No.:921330 Part No.:906170
(order separately)
