ETS 300 15
Status: 29.01.2014 HYDAC ELECTRONIC GMBH Part No.: 669651 E
12.2 CONNECTION DIAGRAM
Sensor resistance
ETS 38X
connector
4-pol. M12x1
4-pole connector
TFP 104 (Binder, Serie 714)
or TFP 106 (M12x1)
