ETS 300 11
Status: 29.01.2014 HYDAC ELECTRONIC GMBH Part No.: 669651 E
9 Programming enable
The unit has 2 types of programming enable which must both be set to "ON" to change the
settings. The operating programming enable can be set or removed during operation. It provides
protection from unintentional alteration. A programming disable via the main programming enable
has the effect that no change to the settings can be carried out during operation. This serves, for
example, as a safety function or as protection against unauthorised alterations.
9.1 ALTERING THE OPERATING PROGRAMMING ENABLE
9.2 ALTERING THE MAIN PROGRAMMING ENABLE
Switch off supply voltage or disconnect the unit from the supply voltage.
Note:
• If a setting has been changed "PRG" is displayed briefly when the display is switched
over. The new setting is then saved in the unit.
