HydraMaster GTXR+ - Blower Assembly Parts List

9-14: Assemblies and Parts Lists
Blower Assembly Parts List
1 000-001-071 ADAPTER BLOWER INLET - COATED 1
2 000-001-871 ADAPTER BLOWER OUTLET 2.5 - COATED 1
3 000-111-145 BLOWER, 4005 DOMINATOR 1
4 000-015-032 BRACKET, DOMINATOR 4005 MOUNTING - COATED 2
5 000-052-061 BUSHING, 3/8” NPT x 1/4” FPT 2
6 000-033-057 CLAMP, 1” CUSHION LOOP 2
7 000-052-085 ELBOW, 1/4” NPT STREET 2
8 000-068-794 HOSE ASSEMBLY, 3/8” x 17” LG. DRAIN 1
9 000-068-794 HOSE ASSEMBLY, 3/8” x 17” LG. DRAIN 1
10 000-052-293 INSERT, #23 (1/8” NPT x 3/16” BARB) 2
11 000-077-011 KEY, 3/16” X 1 1/2” LONG 1
12 000-094-015 NUT, 3/8”-16UNC HEX 2 WAY LOCKING 4
13 000-106-001 PLUG, 1/8” NPT 1
14 000-143-141 SCREW, 1/4”-20UNC x 0.50” LG. WHIZ LOCK 6
15 000-143-018 SCREW, 3/8”-16UNC X 1.00” LG. HEX HD - GRADE 8 6
16 000-143-200 SCREW, 3/8”-16UNC x 1.50” LG. HEX HD GRADE 8 4
17 000-143-094-1 SCREW, 3/8”-16UNC x 0.75” LG. SOCKET HD 4
18 000-174-004 WASHER, 5/16” FLAT, USS 16
19 000-174-057 WASHER, 3/8” LOCK 2
20 000-174-068 WASHER, BLOWER FEET - COATED 4
Item Part Number Description Qty Item Part Number Description Qty
