4-1: Operating Instructions
4 - Operating Instructions
This section describes how to operate the GTXR +, starting with a description of the dash
assembly (see Figure 4-1).
The front dash assembly includes controls for the:
• System’s ignition switch
• Pump-Out system if included in the conguration
• Pump-In system if included in the conguration
The front dash assembly also includes the temperature control dial; the temperature,
vacuum and pressure gauges; and the hour meter.
Figure 8-1. GTXR + Upper Dash Assembly
Vacuum
Gauge
Pressure
Gauge
Ignition Switch
Choke
Throttle
Temperature
Control Dial
Pump-In/Pump Clutch
Switch
Auto Pump-Out Switch
Hour
Meter
