HydraMaster GTXR+ - Console Assembly Parts List

9-9: Assemblies and Parts Lists
Console Assembly Parts List
1 610-007-737 ASSEMBLY, PUMP 1
2 610-002-754 ASSEMBLY, BLOWER 1
3 610-018-754 ASSEMBLY, DASH - GTXR PLUS 1
4 610-004-728 ASSEMBLY, ENGINE 1
5 610-013-754 ASSEMBLY, EXHAUST - GTXR PLUS 1
6 610-001-729 ASSEMBLY, FRAME 1
7 610-005-754 ASSEMBLY, HEAT EXCHANGER - GTXR PLUS 1
8 610-021-729 ASSEMBLY, ORIFICE 1
9 610-010-729 ASSEMBLY, WATER BOX 1
10 000-010-124 BELT, 9430HD 1
11 000-033-029 CLAMP, SIZE #12 HOSE 2
12 000-033-003 CLAMP, SIZE #4 MINI HOSE 5
13 000-033-005 CLAMP, SIZE #5 HOSE 6
14 000-041-900 COVER, BROW - MACHINE - COATED 1
15 000-041-451 COVER, LEFT SIDE - COATED 1
16 000-041-452 COVER, RIGHT SIDE - COATED 1
17 000-049-118 FILTER, CHEMICAL INLET HIGH PRESSURE 1
18 000-068-967 HOSE, 1/2” I.D. RUBBER x 20” LG. (WB DRAIN) 1
19 000-068-968 HOSE, 1/2” I.D. RUBBER x 56” LG. (PUMP TO WB) 1
20 000-068-969 HOSE, 1/2” I.D. RUBBER x 69” LG.
(FRESH WATER IN TO WB) 1
21 000-068-518 HOSE, 3/16” I.D. TEFLON x 18.25” LG.
(PUMP TO GAUGE) 1
22 000-068-517 HOSE, 3/16” I.D. TEFLON x 23” LG.
(CHEM PUMP TO PRIME &
CHEM METERING TO SOL OUT) 2
23 000-068-888 HOSE, 3/16” I.D. TEFLON x 24” LG.
(HX TO ORIFICE ASSY) 1
24 000-068-203 HOSE, 3/16” I.D. TEFLON x 34” LG.
(ORIFICE ASSY TO WB) 1
25 000-068-627 HOSE, 3/16” I.D. TEFLON x 44” LG.
(ORIFICE ASSY TO REC TANK) 1
26 000-068-970 HOSE, 3/4” I.D. RUBBER x 50” LG. (PUMP TO WB) 1
27 000-068-980 HOSE, 3/8” I.D. CLEAR w/ BRAID x 28.5” LG.
(CHEM JUG TO FLOW) 1
28 000-068-971 HOSE, 3/8” I.D. CLEAR w/ BRAID x 60” LG.
(CHEM PUMP TO FLOW) 1
29 000-068-972 HOSE, 3/8” I.D. RUBBER x 76” LG.
(CHEM PRIME TO REC TANK) 1
30 000-068-587 HOSE, 3/8” I.D. THROB x 17.5” LG. (THROB) 1
31 000-068-724 HOSE, 5/16” I.D. TEFLON x 18” LG. (HX TO SOL OUT) 1
32 000-068-978 HOSE, 5/32” I.D. VACUUM x 52” LG.
(BLOWER TO LUBE PORT) 1
33 000-068-977 HOSE, 5/32” I.D. VACUUM x 82” LG.
(BLOWER TO VAC GAUGE) 1
34 000-052-102 INSERT, #46 (1/4” NPT x 3/8” BARB) 1
35 000-105-012 PLATE, MACHINE SERIAL I.D. 1
36 000-140-001 RIVET, AB4-3A ALUMINUM POP 1/8” x 1/4” LG.
(GRIP RANGE 0.126”-0.187”) 2
37 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 11
38 000-174-001 WASHER, #10 FLAT 11
39 000-174-014 WASHER, #10 LOCK 9
Item Part Number Description Qty Item Part Number Description Qty
