7-1: Electrical System
7 - Electrical System
This section describes how the electrical system functions in the following manner:
Electrical System Information
Electrical Schematic
Wiring Diagram
ELECTRICAL SYSTEM INFORMATION
The GTXR + electrical system operates on 12 V DC which is provided by the battery.
Battery levels are maintained by a 20 Amp alternator mounted on the engine.
When a new battery is installed, check that it is properly charged before installation
or damage to the charging system may occur.
