9-42: Assemblies and Parts Lists
70 Gallon Fresh Water Tank (FWT) Assembly Parts List
1 000-015-1238 BRACKET, 70 FWT MOUNTING - COATED 2
2 000-033-004 CLAMP, SIZE #6 MINI HOSE 2
3 000-033-029 CLAMP, SIZE #12 HOSE 5
4 000-041-892 COVER, 4” ROUND POLYCARBONATE - RAW 1
5 000-052-087 ELBOW, 1/2” NPT STREET 2
6 000-052-086 ELBOW, 3/8” NPT STREET 1
7 000-052-348 ELBOW, 3/4” NPT x 1” HOSE 1
8 - - - FILTER, FLOJET PUMP (COMES w\ 000-111-170) 1
9 000-057-254 GASKET - 4 IN. COVER LID 1
10 000-068-964 HOSE, 1” I.D. RUBBER x 36” LG. - RED 1
11 000-068-975 HOSE, 1/2” I.D. RUBBER x 32” LG. 1
12 000-068-973 HOSE, 3/4” I.D. RUBBER x 2.5” LG. 1
13 000-068-965 HOSE, 3/4” I.D. RUBBER x 16” LG. 1
14 000-068-974 HOSE, 3/4” I.D. RUBBER x 30” LG. 1
15 000-052-105 INSERT, #68 (3/8” NPT x 1/2” BARB) 1
16 000-052-129 INSERT, #812, 1/2NPT X 3/4 HOSE 2
17 - - - INSERT, FLOJET PUMP IN (COMES w/ 000-111-170) 1
18 - - - INSERT, FLOJET PUMP OUT (COMES w/ 000-111-170) 1
19 000-052-326 NIPPLE, 3/4” NPT CLOSE 1
20 000-052-075 NIPPLE, 3/8” NPT x 1/2” NPT 1
21 000-094-015 NUT, 3/8”-16UNC HEX 2-WAY LOCKING 4
22 000-094-038 NUT, 5/16”-18UNC NYLOCK 4
23 000-105-668 PLATE, SIDE - COATED 2
24 000-111-170 PUMP, FLOJET W/ BLADDER 40 PSI FRESH WATER 1
25 000-052-053 QUICK CONNECT, 3/8 FEMALE 1
26 000-052-052 QUICK CONNECT, 660 3/8” BRASS W/ EPDM O-RING 1
27 000-143-018 SCREW, 3/8”-16UNC x 1” LG. HEX HEAD - GRADE 8 12
28 000-143-012 SCREW, 5/16”-18UNC x 3/4” LG. 4
29 000-143-314 SCREW, #8 x 1/2” LG. PAN HEAD 6
30 000-159-182 TANK, 70 GALLON FRESH WATER ROTOMOLDED 1
31 000-169-202 VALVE, 3/4” FPT BALL VALVE 1
32 000-174-021 WASHER, 3/8” LOCK 8
33 000-174-005 WASHER, 3/8” FLAT Z/P 16
34 000-174-049 WASHER, 5/16” FLAT 8
Item Part Number Description Qty Item Part Number Description Qty
