HydraMaster GTXR+ - Pump Assembly Parts List

9-19: Assemblies and Parts Lists
Pump Assembly Parts List
1 000-001-096 ADAPTER, CHEM. PUMP TO COMET 1
2 610-009-747 ASSEMBLY, BY-PASS VALVE - CTS 400 FLEX 1
3 000-036-008 CLUTCH, 7” O.D. 24mm SINGLE GROOVE 1
4 000-052-084 ELBOW, 1/8” NPT STREET 1
5 000-052-531 ELBOW, 1/8” NPT x 1/4” SAE 2
6 000-052-086 ELBOW, 3/8” NPT STREET 1
7 000-068-219 HOSE, DRAIN 1
8 000-052-099 INSERT, #26 (1/8” NPT x 3/8” BARB) 1
9 000-052-129 INSERT, #812, 1/2NPT X 3/4 HOSE 1
Item Part Number Description Qty Item Part Number Description Qty
10 000-094-038 NUT, 5/16”-18UNC HEX NYLOCK 2
11 000-097-057 O-RING, ADAPTER - CHEMICAL PUMP 1
12 000-105-148 PLATE, CLUTCH MOUNT COMET PUMP 1
13 000-111-184 PUMP, GP CHEMICAL 1
14 000-111-042 PUMP, HYDRAPUMP II 1
15 000-143-375 SCREW, 5/16”-18UNC x 1.75” LG. HEX HD GRD. 8 Z/P 2
16 000-143-012 SCREW, 5/16”-18UNC x 3/4” LG. 2
17 000-143-221 SCREW, M6-1 X 14MM LG. HEX HEAD 4
18 000-174-004 WASHER, 5/16” FLAT, USS 6
