9-27: Assemblies and Parts Lists
Figure 8-22. Differential Check Valve Assembly
000-169-236 Rev. B
Differential Check Valve Assembly Parts List
1 000-005-012 Ball, 0.500 Dia Stainless Steel 1
2 000-107-258 Body, Differential Check Valve 1
3 000-106-180 Cap, Differential Check Valve 1
4 000-097-056 O-Ring, Check Valve Plug, AN Size -118-Vit 1
5 000-097-054 O-Ring, Chem. Pump Valve Viton-Parker 2-114 1
6 000-148-012 Seat, Differential Check Valve 1
7 000-155-106 Spring, Differential Check Valve 1
Item Part Number Description Qty Item Part Number Description Qty
