9-26: Assemblies and Parts Lists
Dash Assembly Parts List
1 000-001-148 ADAPTER, 2.5” EXHAUST TURNDOWN - COATED 1
2 000-025-003 CABLE, CHOKE WITH DETENT 1
3 000-025-045 CABLE, THROTTLE - TURN TO LOCK 1
4 000-052-272 CUP, GRAVITY FEED OIL BLOWER LUBE PORT 1
5 000-052-088 ELBOW, 1/4” FPT x FPT 1
6 000-052-532 ELBOW, 1/4” SAE x 1/4” NPT 1
7 000-052-084 ELBOW, 1/8” NPT STREET 1
8 000-052-531 ELBOW, 1/8” NPT x 1/4” SAE 1
9 000-074-007 GAUGE, PRESSURE 0 -1500 PSI, UPC #401406. 1
10 000-074-017 GAUGE, 30” HG. VACUUM - HYDRAMASTER 1
11 000-052-099 INSERT, #26 (1/8” NPT x 3/8” BARB) 3
12 000-052-104 INSERT, #66 (3/8” NPT x 3/8” BARB) 1
13 000-052-105 INSERT, #68 (3/8” NPT x 1/2” BARB) 2
14 000-052-096 INSERT, #F23 (1/8” FPT x 3/16” BARB) 1
15 000-081-415 LABEL SET, BOXXER 318 1
16 000-074-030 METER, CHEMICAL FLOW RAW 1
17 000-074-170 METER, RECTANGULAR HOUR w/o BEZEL 1
18 000-052-527 NIPPLE, 1/4” SAE x 1/4” NPT 1
19 000-052-530 NIPPLE, 1/4” SAE x 1/8” NPT 1
20 000-052-069 NIPPLE, 1/8” NPT HEX 1
21 000-052-528 NIPPLE, 3/8” M JIC x 3/8” NPT 1
22 000-052-073 NIPPLE, 3/8” NPT x 1/4” NPT HEX 1
23 000-094-009 NUT, 1/4”-20UNC NYLOCK 4
24 000-094-070 NUT, 5MM HEX NYLOCK 4
25 000-094-098 NUT, 7/16”-24UNF - 2 WAY METERING VALVE 1
26 000-100-310 PANEL, DASH, STEEL - COATED 1
27 000-100-372 PANEL, GRILL - COATED 1
28 000-052-051 QUICK CONNECT, 440 FEMALE w/ EPDM O-RING 1
29 000-052-052 QUICK CONNECT, 660 3/8” BRASS W/ EPDM O-RING 1
30 000-135-052 REGULATOR, HI PSI SNUBBER 1
31 000-143-166 SCREW, #10-24UNC x 0.375” LG. HEX HEAD 2
32 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 8
33 000-143-171 SCREW, #10-24UNC x 1.25” LG. HEX HEAD 4
34 000-157-040 SWITCH, 20 AMP ROCKER 1
35 000-157-131 SWITCH, 3 WAY SPEED CONTROL 1
36 000-052-090 TEE, 1/4” NPT BRANCH M-F-F 1
37 000-149-025 THERMOSTAT, BULB & CAPILLARY 1
38 000-131-131 TRIMLOK, 3/8” x 1/8” RUBBER 1
39 000-169-0171 VALVE, 3-WAY BALL O-RING STYLE 1
40 000-169-064 VALVE, 3/8” NPT FULL PORT BALL 1
41 000-169-160 VALVE, CHEMICAL METERING 1
42 000-169-236 VALVE, DIFFERENTIAL 1
43 000-174-001 WASHER, #10 FLAT 14
44 000-174-014 WASHER, #10 LOCK 2
45 000-174-007 WASHER, 1/2” FLAT 3
46 000-174-062 WASHER, 1/2” I.D. x 3/4” O.D. x 0.010” THK 1
47 000-174-003 WASHER, 1/4” FLAT S/S 4
48 000-174-058 WASHER, 21/32” I.D. x 27/32” O.D. NYLON 1
49 000-174-032 WASHER, 3/8” FLAT 2
50 000-174-008 WASHER, 5/8” FLAT 4
51 000-174-030 WASHER, 5/8” I.D. x 7/8” O.D. x 0.010” THK 1
52 000-174-038 WASHER, 7/16” FLAT SAE 1
Item Part Number Description Qty Item Part Number Description Qty
