Page 1-38 MAXX 450D/470/Diesel
HydraMaster Corporation
Item Part Number Description Qty
Lower Dash Plumbling Connection Panel Assembly Parts List
1 000-100-094 Panel, Lower Dash Plumbing Connection 1
2 000-090-008 Manifold, Hi Pressure 1
3 Fig. 1-29 Assembly, Hi-PSI Manifold - Maxx 450D/470D 1
4 000-052-052 Quick Connect, 660 Male w/ Viton Standard 1
5 000-052-050 Quick Connect, 440 Male w/ Viton Standard 2
6 000-052-272 Cup, Gravity Feed Oil Blower Lubrication Port 1
7 000-052-086 Elbow, 3/8" NPT Street 1
8 000-052-074 Nipple, 3/8" NPT Hex 1
9 000-174-007 Washer, 1/2" Flat 4
10 000-174-032 Washer, 3/8" Flat 2
11 000-174-008 Washer, 5/8" Flat 1
12 000-052-071 Nipple, 1/4" NPT Hex 2
13 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 1
14 000-052-532 Elbow, 1/4" SAE x 1/4" JIC x 90° 1
15 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 2
16 000-143-542 Screw, 1/4"-28UNF x 0.50" Lg. 2
17 000-155-053 Spring, 1/4" Belleville Washer 2
18 000-106-009 Plug, 1/8" NPT Allen Head 1
19 Fig. 1-30 Assembly, By-Pass Valve - Maxx 450DD 1
20 000-052-096 Insert, #F23 (1/8" FPT x 3/16" Barb) 1
21 000-052-142 Elbow, 3/8" FPT x FPT 1
22 000-052-105 Insert, #68 (3/8" NPT x 1/2" Barb) 1
23 000-068-513 Hose, 3/8" x 10" Teflon w/ F JIC End & 3/8" NPT 1
24 000-131-131 Trimlok, 3/8" x 1/8" 1
