HydraMaster MAXX 450D - Page 61

MAXX 450D/470/Diesel Page 1-49
HydraMaster Corporation
CAT 3CP Pump Assembly Parts List
Item Part Number Description Qty
6 000-052-085 Elbow, 1/4" NPT Street 2
7 000-052-710 Elbow, 1/2" NPT x 45° Street - Modified 1
8 000-052-107 Insert, #88 (1/2" NPT x 1/2" Barb) 1
9 000-052-023 Tee, 3/8" NPT Male Street 1
10 000-169-050 Valve, High Pressure Safety (2200) 1
11 000-052-061 Bushing, 3/8" NPT x 1/4" FPT 1
12 000-052-128 Nipple, 3/8" NPT x 3/8" Male Propane 2
13 000-001-082 Adapter, Chemical Pump To CAT 3CP 1
14 000-097-057 O-Ring, Adapter - Chemical Pump 1
15 000-174-019 Washer, 1/4" Lock 4
16 000-143-221 Screw, M6-1 x 14mm Lg. Hex Head 4
17 000-052-106 Insert, 1/8" NPT x 5/32" Barb x 90° 1
18 000-068-523 Hose, 3/8" x 17" Lg. Hi Temp Oil Drain 1
19 000-033-005 Clamp, Size #5 Hose 1
20 000-068-587 Hose, Throb 1
21 000-052-656 Plug, SAE Flare For Throb Hose - Maxx 1
22 000-052-160 Insert, 3/4" M Garden x 1/2" Barb 1
23 000-068-086 Hose, 1/2" I.D. Hi-Temp 1
24 000-033-006 Clamp, Size #8 Hose 2
25 000-027-116 Cap, Garden Hose - Modified 1
26 000-057-055 Gasket, Garden Hose 1
27 000-169-176 Valve, 2 Way Chemical Pump 1
28 000-052-517 Nipple, 1/4" NPT Close 1
29 Fig. 1-21 Assembly, Chemical Pump - Boxxer 427 1
30 000-052-099 Insert, #26 (1/8" NPT x 3/8" Barb) 1
31 000-052-530 Nipple, 1/8" MNPT x 1/4" SAE 1
32 000-015-933 Bracket, Chemical Pump Support 1
33 000-174-049 Washer, 5/16" Flat 4
34 000-094-013 Nut, 5/16"-24UNF Hex 4
35 000-052-753 Insert, #816 (1/2" NPT x 1" Barb) 1
