MAXX 450D/470/Diesel Page 1-63
HydraMaster Corporation
Item Part Number Description Qty
Exhaust Assembly Parts List
1 000-093-066 Catalytic Converter With Flanges 1
2 000-169-045 Valve, Cast Exhaust Diverter 1
3 000-125-113 Tube, Exhaust To Cat. - Engine Side 1
4 000-125-121 Tube, 1.50 Final Exhaust 1
5 000-052-642 Elbow, 1.50 With Flanges 1
6 000-125-116 Tube, Y Exhaust 1
7 000-057-177 Gasket, Exhaust Donut 1.50" 3
8 000-015-631 Bracket, Air Cylinder Actuation 1
9 000-038-045 Assembly, After Burner Heat Exchanger 1
10 000-057-146 Gasket, Four Hole Exhaust Diverter 3
11 000-125-128 Tube, 1-3/8" OD x 1/8" Wall x 7/8" Long 3
12 000-143-572 Screw, 5/16"-18UNC x 5/8" Lg. Hex Grd. 5 12
13 000-174-049 Washer, 5/16" Flat 20
14 000-143-124 Screw, 5/16"-18UNC x 1.75" Lg. Hex Head 6
15 000-174-069 Washer, 5/16" Inconel Belleville, Diverter Valve 12
16 000-052-600 Elbow, 1/2" Tube x 3/8" FPT 2
17 000-106-008 Plug, 3/8" NPT Allen Head 2
18 000-052-385 Elbow, 3/8" Male Comp.To 3/8" NPT Inverted Flare 1
19 000-033-068 Clamp, 1-1/2" Muffler 3
20 000-001-087 Adapter, Final Exhaust 1
21 000-155-030 Spring, Leaf 1
22 000-138-010 Retainer, Leaf Spring 1
23 000-094-027 Nut, #10-24UNC Hex 2
24 000-103-014 Pin, 1/8 x 3/4" Roll 1
25 000-094-081 Nut, 5/16"-18UNC Hex 2-Way Locking 13
26 000-143-132 Screw, #10-24UNC x 0.75" Lg. Hex Head 2
27 000-125-131 Tube, Exhaust To Cat. - Cat. Side 1
28 000-125-172 Tube, Air Pump - N/S - Maxx 450D/470D 1
29 000-015-725 Bracket, Exhaust Support - Maxx 450D/470D 1
30 000-015-756 Bracket, After Burner & Exhaust Cover 1
