MAXX 450D/470/Diesel Page 1-65
HydraMaster Corporation
HI-PSI Manifold Assembly Parts List
Item Part Number Description Qty
1 000-090-010 Manifold, Hi-PSI 1
2 000-180-006 Orifice, Set Screw 0.061" 1
3 000-180-004 Orifice, Set Screw 0.033" 1
4 000-052-423 Bushing, Modified Set Screw Orifice 2
5 000-149-039 Sender, Temperature 1
6 000-169-177 Valve, 3/8" FPT Check 65 PSI 1
7 000-049-016 Filter, 1/4" NPT Replacement “Y” 2
8 000-052-074 Nipple, 3/8" NPT Hex 1
9 000-052-086 Elbow, 3/8" NPT Street 1
10 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 1
11 000-052-532 Elbow, 1/4" SAE x 1/4" JIC x 90° 1
12 000-106-111 Plug, 1/2" NPT Allen 2
13 000-149-540 Sensor, RTD Compresion Fitting Style 1
14 000-155-020 Spring, 0.540 O.D. x 0.041 Wire x 1.00 Lg. 2
15 000-052-082 Elbow, 1/4" NPT Street x 45° 1
16 000-052-527 Nipple, 1/4" SAE x 1/4" NPT 1
17 000-052-587 Compression, 3/16" x 1/4" NPT Thermocouple Fitting 1
