WeatherTRAK 2-Wire Controller Installation Guide
18
©
2020 HydroPoint Data Systems Inc. All rights reserved. 800.362.8774 • hydropoint.com
When assigning decoders, the display screen will look something like this:
L
ine 1 shows the screen name/number and the current time.
Line 2 is the device ID and the decoder’s address assignment. In this example, the device is a valve decoder
on station number 01.
Line 3 is the decoder’s type and power level. In this example, the decoder is a single valve decoder. The PWR
level defaults to low.
Line 4 is the action you take to assign the decoder with an address that matches that station. In this example,
you would press the * button.
Navigation:
You use the buttons on the control panel to navigate through the screens when programming the decoders.
Below is a chart which explains each action.
To Exit press
To go back to start: Press
To take an action: Press *
To change the device ID or power level: press + or -
Assigning a Single Valve Decoder to a Station
Plug the decoder into the terminal located on the mini-chassis board.
Press SETUP.
Press until CONFIGURE H2O 2-WIRE displays (setup 15).
Press + or – until Program decoders displays.
Press SELECT.
Press *. The controller reads the decoder and assigns it to the next station in sequence. If you need to
change the station number, press
+ or –.
Press * to assign the decoder to the station shown.
Press + or – to set the power level. Power levels for each station can be adjusted independently. The
power defaults to low. For most stations, low power is sufficient.
