Maximum Concurrent Valves
The maximum number of concurrently operating valves is shown in the two tables below. The number of
concurrent valves varies based on the total load count and wire length to the farthest device:
Decoder and Sensor Load Count
Maximum Concurrent Valves -#12 Wire
Wire Length (ft)
1000-3000
4000
5000
6000
7000
8000
100
15
14
13
8
6
4
90 15 15 14 9 7 5
80
15
15
15
10
8
6
70 15 15 15 11 9 7
60
15
15
15
12
10
8
50 15 15 15 13 11 9
40
15
15
15
14
12
10
30 15 15 15 15 13 11
20
15
15
15
15
14
12
10 15 15 15 15 15 13
Decoder and Sensor Load Count
Maximum Concurrent Valves -#14 Wire
Wire Length (ft)
1000
2000
3000
4000
5000
100 13 11 8 4 2
90
14
12
9
5
3
80
15
12
10
6
4
70
15
13
11
7
5
60
15
14
12
8
6
50
15
15
13
9
7
40
15
15
14
10
8
30 15 15 15 11 9
20
15
15
15
12
10
10 15 15 15 13 11
