Press * to assign the decoder. The following screen displays, confirming a successful assignment:
Label the decoder then unplug it from the Station Program terminal.
To assign the next decoder, press . To exit, press .
Assigning a Pump Start Decoder
Refer to the chassis board drawing for connection locations before beginning. The Pump Start Decoder will
reduce station count by 1.
When programming a decoder to a pump start, you must match the station number to the pump
start number. For example: POC 1 must be assigned to station 1. POC 2 must be assigned to
station 2, POC 3 must be assigned to station 3 and POC 4 must be assigned to station 4.
Programming a pump start decoder is done in two parts. You will need to first assign the decoder then you
will need to configure it to the POC.
Assigning the decoder
Plug the decoder into the terminal located on the mini-chassis board.
Press SETUP.
Press until CONFIGURE H2O 2-WIRE displays (setup 15).
Press + or – until Program Decoders displays.
Press SELECT.
Press *. The controller reads the decoder. PS1-4 will display.
Make sure to select the correct pump start location by pressing + or -.
Press * to assign the decoder.
Press + or – to set the power level. Power levels for each station can be adjusted independently. The
power defaults to low. for most stations, low power is sufficient. However, some stations may require more
power due to a longer 2-wire path or a higher electrical requirement for a specific valve type.
