Hypertherm Command THC User Manual

SETUP
CommandTHC for X-Y Table Instruction Manual 3-5
11
X-Y lifter assembly
• Mount the X-Y lifter assembly on the cutting table. See Figure 3-3.
THC.68
3.5"
(89 mm)
3.5"
(89 mm)
3.5"
(89 mm)
22.4"
(570 mm)
2.875"
(73 mm)
4.5"
(114 mm)
5.0"
(127 mm)
2.8"
(71 mm)
1/4-20
2.12"
(54 mm)
1.75"
(44.5 mm)
1.26"
(32 mm)
1.42"
(36 mm)
1.41"
(36 mm)
8.0"
(203 mm)
3.25"
(82.6 mm)
1/4" (6 mm)
Figure 3-3 X-Y lifter assembly mounting
