SETUP
3-12 CommandTHC for X-Y Table Instruction Manual
9
System interconnections
Cable part numbers and signal lists are provided in figures 3-14 through 3-18.
THC system cables
HT4400 and HPR installation
Note: Instructions to install the plasma interface PCB into the HT4400 power supply are
included in section 3h.
Instructions to install the plasma interface PCB into the HPR power supply are
included in section 3i.
The plasma interface enclosure is not used for the HT4400.
Caution: Do not run the pendant cable in parallel and near to the torch lead.
There is a possibility that electrical noise will cause erratic
operation of the operator pendant or damage it.
Install system cables as shown in Figure 3-8.
