Instruction Manual
3-15
11
2
1
THC.87
1
3.
Install the machine interface cable as shown in Figure 3-11.
Figure 3-11
Machine interface cable
Figure 3-12
Machine interface cable grounding
4.
If installation requires removal of a cable connector, all
wires must be properly terminated, including shield, or
system problems may occur
. See Figure 3-12.
Machine interface cable
Not used
2
1
CN
C
TH
C
Control
Module
68
70
