APPENDIX A: ARGON-HYDROGEN CUTTING AND GOUGING
a-8 HySpeed HT2000LHF Instruction Manual
6
Argon-Hydrogen Cut Charts
The Argon-Hydrogen Cut Charts on the following pages provide the necessary information for the operator using
the HT2000LHF system to be successful in plasma arc cutting and gouging using argon-hydrogen as the plasma
gas. The HT2000LHF provides a wide travel speed operating window: usually ± 10 ipm (± 254 mm/min) on most
materials. The data listed in the charts are for making drop cuts with minimal dross.
Caution: Before cutting, check all settings and adjustments and check for damaged torch
parts and worn consumable parts.
Argon-Hydrogen Cut Chart and Consumable Parts Index
Plasma Gas/ Retaining Swirl
Metal Amps Shield Gas Shield Cap Nozzle Ring Electrode Page
Stainless
Steel
Stainless
Steel
&
Aluminum
Aluminum
200 H35 / N
2
020602 120837 020608 020607 020415 a-9
100 H35 / N
2
020448 120837 020611 020607 020415 a-10
200 H35 / N
2
020602 120837 020608 020607 020415 a-11
100 H35 / N
2
020448 120837 020611 020607 020415 a-12
200 H35 / N
2
020485 120837 020615 020607 020415 a-13
