Hypertherm Powermax30 AIR Operator's Manual

Powermax30 AIR Operator Manual 808840 15
Section 1
Specifications
Safety information
Before operating any Hypertherm equipment, read the separate Safety and Compliance Manual (80669C) included with
your product for important safety information.
System description
The Powermax30 AIR is a 30 A handheld plasma cutting system that contains its own internal air compressor for
maximum portability and ease of use. With it, you can cut electrically conductive metals – such as mild steel, stainless
steel, or aluminum – of thicknesses up to 10 mm (3/8 inches). You can also pierce thicknesses up to 6 mm (1/4 inch).
The Powermax30 AIR ships in several different configurations, based on region. Typically all configurations include:
 1 complete set of consumables (preinstalled on the Air T30 hand torch):
 1 electrode
 1 swirl ring
 1 nozzle
 1 retaining cap
 1 deflector
 1 extra nozzle
 1 extra electrode
 Carrying strap
 Operator Manual
 Safety and Compliance Manual
 Quick Setup Card

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
