18 Powermax30 AIR Operator Manual 808840
1 – Specifications
Torch dimensions
Torch weight
 Air T30 torch with consumables only: 0.3 kg (0.65 pounds)
 Air T30 torch with consumables and 4.6 m (15 foot) lead (with strain relief): 1.0 kg (2.25 pounds)
25 mm
(1.0 inch)
51 mm (2.0 inches)
230 mm (9.0 inches)
45 mm
(1.8 inches)
86 mm
(3.4 inches)
75°
