Hypertherm Powermax30 AIR Operator's Manual

62 Powermax30 AIR Operator Manual 808840
6 – Parts
Power supply parts
Exterior, front
Item Kit number Description
1 228267 Kit: Power supply handle (includes screws and shoulder strap clips)
2 428226 Kit: Current adjustment knob
3 228561 Kit: Ground clamp
1
2
3

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
