Hypertherm Powermax30 AIR Operator's Manual

16 Powermax30 AIR Operator Manual 808840
1 – Specifications
CSA units ship with a 120 V / 15 A (NEMA 5-15P) adapter and a 240 V / 20 A (NEMA 6-50P) adapter that connect to
the NEMA twist lock-style 240 V / 20 A (NEMA L6-20P) plug wired to the power supply. CE units ship without a plug on
the power cord. See Power cord considerations on page 27 for more information.
You can order additional consumables and accessories – such as a dust cover and circle cutting guides, for example –
from any Hypertherm distributor. See Parts on page 61 for a list of spare and optional parts.
Power supply dimensions
System weights
The following system weights include the hand torch with 4.6m (15foot) torch lead, a 4.6m (15foot) work lead with
ground clamp, and a 3.0 m (10 foot) power cord:
 CSA systems: 13.5 kg (29.8 pounds)
 CE systems: 13.4 kg (29.5 pounds)
420 mm
(16.5 inches)
195 mm
(7.7 inches)
333 mm
(13.1 inches)
295 mm
(11.6 inches)

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
