Machine Interface Receptacle with Voltage Divider Board
Powermax45 XP Field Service Bulletin 809940 3
Introduction
This Field Service Bulletin gives the procedure for installing an internal machine interface
receptacle, cables, and voltage divider printed circuit board (PCB).
Tools and materials
Assorted Phillips
®
, TORX
®
, and blade screwdrivers
Grounded wrist strap (or similar grounding accessory)
Kit 428653 contents
WARN ING
ELECTRIC SHOCK CAN KILL
Disconnect electrical power before doing installation or maintenance.
All work requiring removal of the plasma power supply outer cover or panels
must be done by a qualified technician.
See the Safety and Compliance Manual (80669C) for more safety
precautions.
NOTICE
Static electricity can cause damage to printed circuit boards (PCBs). Use correct
precautions when you touch PCBs.
Keep PCBs in antistatic containers.
Put on a grounded wrist strap when you touch PCBs.
Part number Description Quantity
075534 Plastite #6 X 5/16 pan head screw 2
223476 Machine interface receptacle with cables and voltage divider PCB 1
074391 Cable holder 2
