Hytera PNC550 - Page 15

Exploded View and Packaging Guide
B9
8
No. Part No. Description Qty No. Part No. Description Qty
8 5110010060061A
Waterproof and
breathable film for
silicone rubber Mic
2 40 5110990060129A Screw plug 2
9 50100500060001
Front camera
1 41 5113070000052A
Double-sided
adhesive tape for rear
camera
2
10 11500000005576 Keyboard FPC 1 42 5116000000843A Camera lens 2
11 5110030060104A Waterproof ring 1 43 5121000060167A NFC antenna 1
12 5112010060004A
Metal dome
1 44 5116000002850A
Battery cover
1
13 5113020060025A Floodlight diffuser film 1 45 5116000002851A Battery latch 1
14 5110010000044A
Light-sensitive silicone
rubber case
1
46 5113050060021A Buffer foam 2
15 11500000005575
Light-sensitive and
tricolor light FPC
1 47 5111000002417A
Fixing sheet
1
16 5113070060028A
Double-sided adhesive
tape for light-sensitive
FPC
1 48 32010000000243
Smart Li-ion battery
pack
1
17 5116000002910A
Photosensitive light
bracket
1
49 5116000060010A
Diversity antenna
FPC
1
18 5113070060122A
Double-sided adhesive
tape for photosensitive
light bracket
1 50 5113050000275A BTB preloaded foam 10
19 5116000002848A PTT key bracket 1 51 5105050060126A RF cable 1
20 51020500000011
Receiver
1 52 11500000005573
Main-deputy board
FPC
1
21 5115020060043A
Main board conductive
foam 1
1
53 5107000000041A Self-tapping screw 5
22 5115020060044A
Main board conductive
foam 2
1
54 11500000005572
Type-C switching
FPC
1
23 5115020060085A
Main board conductive
foam 3
1 55 5116000002849A
PTT key cover
1
24 54991010002021 Main board 1 56 11500000005570
Deputy board
(earpiece board)
1
25 5116000060021A LTE antenna and bracket 1 57 5116000002911A P&R key 1
26 5107000000371A
Machine screw
6 58 51020600000141
Speaker
1
27 50100500060022 Rear camera 1 59 5116000002857A Speaker bracket 1
28 5113990000157A Front camera foam 1 60 5110030060105A
Waterproof ring for
speaker
1
29 5113990060123A
Preloaded foam for
flashlight FPC
1 61 5113040060022A
Speaker dustproof net
1
30 11500000005574 Flashlight FPC 1 62 5111000002418A Charger spring plate 2
31 5113070060027A
Double-sided adhesive
tape for flashlight FPC
pin
1 63 5118000000294A Charging piece 2
