Hytera PNC550 - Camera Circuit

B9
Troubleshooting Flowchart
27
6.1.5 Camera Circuit
Rep la ce the camer a.
Is t he cam era no rmal? [1]
Are J11 00 an d J1101
connected normally? [2]
No
Yes
End
Yes
No
Are the peripheral
comp one nt s of J11 00 an d J1101
normal? [3]
Rep la ce the main b oard .
Re-sold er or rep lace
J11 00 and J11 01.
Re-sold er or rep lace the
comp one nt s.
Yes
No
St art
End
Description of normal situations:
[1] The camera photographs clearly without anomaly.
[2] The connectors are soldered properly without damage.
[3] The components are soldered properly without damage.
