Part List
73
12. Part List
12.1 Main Board
12.1.1 Baseband
No.
Priorit
y
Part No. Description Qty Print No.
1 A F1110000082-01 IC, PMIC for power 1 U300
2 A F1110000083-01 IC, BB 1 U800
3 A L1115060006-01 IC, eMMC+LPDDR3 1 U801
4 A F1110000072-01 IC, PMIC for interface 1 U100
5 A F1154000041-01 IC, OVP Switch 1 U200
6 A L2410000011-01 Silicon Microphone 1 M900
7
A L2815000061-01 Nch+Pch MOSFET
1 U1005
B L2815000065-01 N and P Channel MOSFET
8 A F1152000092-01 IC, Electronic Compass 1 U901
9 A L1152000141-01 IC, Accelerometer 1 U900
10
A S1430000005-01 BRT, NPN
2 Q1000, Q1001 B S1430000004-01 BRT, NPN
C L1430000017-01 Digital Transistor, NPN
11
A S3474023100-01 IND-P, 10μH
1 L100
B S3474033100-01 IND-P, 10μH
C F3474043100-01 IND-P, 10μH
D F3474043100-02 Power Inductor, 10μH
E F3474043100-03 Power Inductor, 10μH
12
A F3474042100-01 IND-P, 1.0μH
1 L101 B F3474052100-02 IND-P, 1.0μH
C F3474052100-01 IND-P, 1.0μH
13
A F3474072100-01 IND-P, 1μH
2 L300, L301
B L3474032100-02
IND-P, 1.0μH
