Hytera PNC550 - Page 81

Part List
B9
74
No.
Priorit
y
Part No. Description Qty Print No.
14
A F3474002200-01 IND-P, 2.2μH
3 L302, L303, L306 B F3474912220-02 IND-P, 2.2μH
C F3474922100-01 Power Inductor, 2.2μH
15
A F3474001470-01 IND-P, 0.47μH
2 L304, L305
B F3474041470-01 Power Inductor, 0.47μH
16
A F1411000017-01 Schottky Barrier Diode
2 D100, D101
B L1411000031-01 Schottky Barrier Diode
17
A F1411000018-01 Schottky Barrier Diode
2 D200, D201
B F1411000028-01 Schottky Barrier Diode
18 A S2815000006-01 Filter 1 T1018
19 A F2815000037-01 Filter 1 D1001
20
A F2815000023-01 Filter, bi-directional
4 T1019, T1035, T1040, T1041 B F2815000024-01 Filter, bi-directional
C F2815000025-01 Filter, bi-directional
21
A F2815000026-01 Filter, bi-directional
44
T901, T902, T903, T904, T905, T906,
T930, T1000, T1001, T1002, T1003,
T1004, T1005, T1006, T1007, T1008,
T1010, T1011, T1012, T1013, T1014,
T1015, T1020, T1021, T1022, T1023,
T1024, T1025, T1026, T1029, T1030,
T1031, T1032, T1033, T1036, T1042,
T1043, T1044, T1045, T1046, T1100,
T1101, T1102, T900
B F2815000027-01 Filter, bi-directional
C F2815000028-01 Filter, bi-directional
22
A F2815000022-01 Filter, unidirection
2 T1016, T1017 B F2815000021-01 Filter, unidirection
C F2815000020-01 Filter, unidirection
23
A S2817000001-01 Bead
4 B900, B901, B902, B903 B S2817000002-01 Bead
C F2817000022-01 Bead
24
A S2817000007-01 Bead
1 B200
B S2817000006-01 Bead
