Hytera PNC550 - Nfc

B9
Part List
87
No. Priority Part No. Description Qty Print No.
14
A F3310415470-02 CAP, 4.7μF
1 C1712
B F3310415470-01 CAP, 4.7μF
15
A S3320416100-03 CAP, 10μF
2 C1702, C1715 B S3320416100-02 CAP, 10μF
C S3320416100-01 CAP, 10μF
16 A S3400019430-01 IND, 4.3nH 2 L1702, L1703
17
A S3400111120-01 IND, 120nH
1 L1704
B F3400111120-01 IND, 120nH
18 A S3400010220-01 IND, 22nH 1 L1707
19
A S3400110820-01 IND, 82nH
2 L1705, L1706
B F3400010820-01 IND, 82nH
20
A S3200019000-01 RES, 0Ω
7
R1700, R1701, R1702, R1703, R1704,
R1706, R1705
B F3200019000-01 RES, 0Ω
21 A F4417000002-01 RF Connector 1 J1700
22 A L4415000019-01 Spring Plate 2 ANT7, ANT8
12.1.4 NFC
No. Priority Part No. Description Qty Print No.
1 A L1151000018-01 IC, NFC Controller 1 U1500
2
A F2211030010-01 Crystal
1 X1500 B F2211030013-01 Crystal
C F2211030011-01 Crystal
3
A S3300810180-01 CAP, 18pF
2 C1519, C1520
B F3300810180-03 CAP, 18pF
4
A S3300810560-01 CAP, 56pF
2 C1502, C1510 B F3300810560-02 CAP, 56pF
C F3300810560-01 CAP, 56pF
