Hytera PNC550 - Wlan

B9
Part List
85
No. Priority Part No. Description Qty Print No.
75
A S3200011120-01 RES, 120Ω
2 R1208, R1209
B F3200011120-01 RES, 120Ω
76
A S3200011220-01 RES, 220Ω
1 R1600
B F3200011220-01 RES, 220Ω
77
A S3200014100-01 RES, 100kΩ
1 R1211
B F3200014100-01 RES, 100kΩ
78
A S3230019000-01 RES, 0Ω
1 R1800
B F3230019000-01 RES, 0Ω
79 A S3268004100-01 NTC Thermistor 1 RT1400
80 A F4417000002-01 RF Connector 2 J1200, J1301
81 A L4313000014-01 Coaxial Connector 1 J1300
82 A L5543000003-01 RF Cable Clip 1 J1302
83 A L4415000018-01 Spring Plate 4 ANT1, ANT2, ANT3, ANT4
The differences between B8 and B9 frequency bands are not updated in this list.
12.1.3 WLAN
No. Priority Part No. Description Qty Print No.
1 A F1151000014-01 IC, WLAN/BT/FM 1 U1700
2 A F2715010033-01
FILTER, WLAN BPF
Coexistence of 4G
1 F1700
3 A S2716020001-01 Duplexer 1 FL1701
4
A S2817000005-01 Bead
1 B1700 B F2817000013-01 Bead
C S2817000004-01 Bead
5
A S3300810120-01 CAP, 12pF
1 C1718
B F3300810120-03 CAP, 12pF
