Hytera PNC550 - Procedures

B9
Disassembly and Reassembly
3
2.3 Procedures
1. Remove the battery.
a. Turn off the radio.
b. Slide the battery latch to the position
○
1 , and then remove the battery cover
○
2 .
c. Press the buckle position on the bottom of the battery, and lift up
○
3
to remove the battery
○
4
.
2. Disassemble the chassis.
a. Use a tweezers to remove the two screw stoppers on the top
○
5 .
Do not scratch the rear cover during operation.
b. Use a T5 screwdriver to remove the 10 screws
○
6 .
c. Remove the chassis
○
7 .
