Hytera PNC550 - Deputy Board (Earpiece Board)

B9
Part List
89
No. Priority Part No. Description Qty Print No.
D S3310415220-04 CAP, 2.2μF
13
A F3310415470-02 CAP, 4.7μF
2 C1513, C1514
B F3310415470-01 CAP, 4.7μF
14 A F3420111160-01 IND, 160nH 2 L1500, L1501
15
A S3200019000-01 RES, 0Ω
4 R1509, R1510, R1503, R1505
B F3200019000-01 RES, 0Ω
16
A S3200012100-01 RES, 1kΩ
2 R1501, R1506
B F3200012100-01 RES, 1kΩ
17
A F3200015100-01 RES, 1MΩ
1 R1513
B F3200015100-02 RES, 1MΩ
18
A S3210019000-01 RES, 0Ω
5 R1502, R1511, R1512, R1515, R1516
B F3210019000-01 RES, 0Ω
19
A S3220019000-01 RES, 0Ω
1 R1504 B F3220019000-01 RES, 0Ω
C F3220019000-02 RES, 0Ω
12.2 Deputy Board (Earpiece Board)
No. Ref No. Part No. Description No. Ref No. Part No. Description
1
/ 5001010003388C
PCB Deputy
Board/Earpiece
Board
47
L1 50040100000582 3.3μH
2 C1 50020100003617 10μF 48 L10 50040200000138 Ferrite Bead
3 C10 50020100000693 0.1μF 49 L13 50040200000137 Ferrite Bead
4 C11 50020100001935 0.1μF 50 L14 50040200000137 Ferrite Bead
5 C12 50020100000834 1000pF 51 L2 50040100000518 3.3μH
6 C14 50020100001190 33pF 52 L4 50040200000138 Ferrite Bead
7 C15 50020100000693 0.1μF 53 L6 50040100000649 120nH
