Part List
B9
90
No. Ref No. Part No. Description No. Ref No. Part No. Description
8 C17 50020100001190 33pF 54 L7 50040200000138 Ferrite Bead
9 C18 50020100001190 33pF 55 L8 50040200000138 Ferrite Bead
10 C19 50020100001190 33pF 56 L9 50040200000138 Ferrite Bead
11 C2 50020100060529 220pF 57 MG1 50150200000017 Motor
12 C20 50020100001392 100pF 58 Q1 50070400000031 P-MOSFET
13 C21 50020100001190 33pF 59 R10 50030100000297 0Ω
14 C22 50020100001935 0.1μF 60 R11 50030100000297 0Ω
15 C23 50020100001190 33pF 61 R12 50030100001971 10kΩ
16 C24 50020100000693 0.1μF 62 R13 50030100001971 10kΩ
17 C25 50020100001190 33pF 63 R14 50030100001130 1kΩ
18 C27 50020100001190 33pF 64 R15 50030100000297 0Ω
19 C28 50020100001190 33pF 65 R16 50030100001971 10kΩ
20 C29 50020100001190 33pF 66 R17 50030100000012 47kΩ
21 C3 50020100001120 22μF 67 R18 50030100000496 1.5kΩ
22 C4 50020100003387 1μF 68 R20 50030100000316 0Ω
23 C5 50020100003387 1μF 69 R21 50030100000316 0Ω
24 C6 50020100000834 1000pF 70 R23 50030100000297 0Ω
25 C7 50020100003387 1μF 71 R24 50030100001210 20kΩ
26 C8 50020100000834 1000pF 72 R25 50030100000297 0Ω
27 C9 50020100000834 1000pF 73 R27 50030100000298 10Ω
28
D1 50050800000184
ESD Protection
Diode
74
R28 50030100000297 0Ω
29
D10 50050800000185
ESD Protection
Diode
75
R29 50030100000316 0Ω
