Part List
B9
82
No. Priority Part No. Description Qty Print No.
31 A L1154000056-01 Switch, SPDT for TRX 1 U1402
32 A L1154000057-01 Switch, SPDT for RX 6
U1200, U1202, U1301, U1601, U1603,
U1604
33 A L1154000055-01 Switch, SP3T for RX 2 S1300, S1600
34 A L2715050001-01 IC, SP12T 1 U1300
35 A S3300810150-01 CAP, 15pF 2 C1228, C1408
36
A S3300810220-01 CAP, 22pF
7
C1628, C1613, C1621, C1623, C1625,
C1225, C1624
B S3300810220-02 CAP, 22pF
37
A S3300800330-01 CAP, 33pF
41
C1400, C1412, C1417, C1352, C1331,
C1316, C1336, C1308, C1319, C1342,
C1300, C1305, C1309, C1314, C1317,
C1320, C1322, C1329, C1332, C1337,
C1340, C1434, C1439, C1436, C1437,
C1629, C1213, C1233, C1234, C1323,
C1205, L1600, L1602, L1604, L1606,
L1608, L1610, L1612, L1614, R1200,
R1204
B S3300810330-01 CAP, 33pF
C F3300810330-02 CAP, 33pF
38
A S3300810560-01 CAP, 56pF
42
C1200, C1202, C1217, C1219, C1303,
C1304, C1306, C1307, C1315, C1318,
C1321, C1330, C1333, C1335, C1341,
C1443, C1447, C1449, C1630, C1637,
C1638, C1643, C1646, C1656, C1659,
C1661, C1663, C1627, C1604, C1632,
C1634, C1614, C1616, C1618, C1620,
C1201, C1218, C1334, C1644, C1645,
C1657, C1658
B F3300810560-02 CAP, 56pF
C F3300810560-01 CAP, 56pF
39
A S3300341100-01 CAP, 100pF
26
C1207, C1214, C1223, C1311, C1312,
C1339, C1454, C1636, C1653, C1654,
C1666, C1668, C1803, C1804, C1208,
C1209, C1428, C1432, C1440, C1442,
C1448, C1427, C1420, C1606, C1626,
C1231
B S3300801100-01 CAP, 100pF
C S3300811100-01 CAP, 100pF
D F3300811100-01 CAP, 100pF
40
A S3300342100-01 CAP, 1nF
14
C1206, C1215, C1224, C1226, C1310,
C1324, C1325, C1338, C1425, C1453,
C1635, C1652, C1665, C1667
B S3300342100-02 CAP, 1nF
C F3300352100-01 CAP, 1nF
41
A S3300323100-01 CAP, 10nF
4 C1600, C1609, C1611, C1421 B S3300323100-02 CAP, 10nF
C F3300323100-01 CAP, 10nF
42
A S3300224100-01 CAP, 100pF
5 C1210, C1457, C1608, C1610, C1612
B S3300214100-01 CAP, 100pF
