Network Camera User Manual
Refer to the Figure 2-2 to set network camera over the LAN via a switch or a router.
or
Network Camera
Network Cable
Computer
Figure 2-1 Connecting Directly
Network Camera Computer
Figure 2-2 Connecting via a Switch or a Router
2.1.2
Activating the Camera
You are required to activate the camera first by setting a strong password for it before you
can use the camera.
Activation via Web Browser, Activation via SADP, and Activation via Client Software are
all supported.
Activation via Web Browser
Steps:
1.
Power on the camera, and connect the camera to the network.
2.
Input the IP address into the address bar of the web browser, and click Enter to enter the
activation interface.
Notes:
The default IP address of the camera is 192.168.1.64.
For the camera enables the DHCP by default, the IP address is allocated automatically.
And you need to activate the camera via SADP software. Please refer to
