2. ACON-C/CG, PCON-C/CG
15
2.3 EtherNet/IP Interface
2.3.1 Names of the Parts
The names of each section related to EtherNet/IP are described as follows.
05 .'&
/5 .'&
Status indicator LEDs
EtherNet/IP port
Status LEDs
