4. SCON-CA
255
z
Fieldbus baud rate
(No. 86: FBRS)
Specify the baud rate
in parameter No. 86.
Set value
Baud rate
0 (Factory setting)
Auto negotiation (recommended)
1
10 Mbps, half-duplex
2
10 Mbps, full-duplex
3
100 Mbps, half-duplex
4
100 Mbps, full-duplex
Other than the above
Baud rate setting error
z
Network type (No.87 NTYP)
The network modul
e type is set for the parameter
No. 87. Do not change the d
efault value.
262
264
